Major Specifications
Seats | 5 |
Capacity | 4 Passengers |
Cruise Speed | up to 110 knots (204 km/h) |
Range | 350 nm (650 km) |
Fuel Capacity | 493 lb (224 kg) |
Maximum Gross Weight | 2700 lb (1225 kg) |
Major Specifications
Seats | 5 |
Capacity | 4 Passengers |
Cruise Speed | up to 110 knots (204 km/h) |
Range | 350 nm (650 km) |
Fuel Capacity | 493 lb (224 kg) |
Maximum Gross Weight | 2700 lb (1225 kg) |
About Robinson R66 HelicopterShort Overview
Robinson is currently the world’s leading manufacturer of civil helicopters. Robinson’s latest model, the R-66 Turbine was FAA certified on 25th October 2010. It is a light single-engine (Rolls Royce RR-300), two-bladed civil utility versatile helicopter. It features an advanced design & latest technologies, such as “Digital Glass Cockpit”, Garmin GTN 750 (GPS, Transmission & Navigation),”Radio Altimeter”, Single Channel Autopilot – “Stability Augmentation System” (SAS), “Emergency Locator Transmitter” (ELT), ADSB Transponder.
All these advanced technologies, ensure excellent comfort all the way. It has improved reserve power, performance, and a large baggage compartment. It is a brand new helicopter and provides passengers with a fully air-conditioned environment in the sky.
Robinson R-66 Specification
Manufacturer | Robinson Helicopter Company, Torrance, California, USA |
Type and Model | Robinson R-66, 2017 (Brand New) |
Crew | One pilot |
Capacity | 4 Passengers (three in the passenger compartment; one beside pilot) |
Engine Type | Rolls-Royce RR300 Turbine |
Horsepower | 300 shp turboshaft; derated to 270 shp for takeoff and 224 shp continuous |
Maximum Gross Weight | 2700 lb (1225 kg) |
Approximate Empty Weight (including oil & standard avionics) | 1407 lb (638 kg) |
Fuel Capacity (73.6 gal) | 493 lb (224 kg) |
Pilot, Passengers, and Baggage (with maximum fuel) | 927 lb (420 kg) |
Cruise Speed at Maximum Gross Weight | up to 110 kts (204 km/h) |
Maximum Range (no reserve) | approximately 350 nm (650 km) |
Hover Ceiling IGE at Maximum Gross Weight | over 10,000 ft |
Hover Ceiling OGE at Maximum Gross Weight | over 10,000 ft |
Rate of Climb | over 1000 fpm |
Maximum Operating Altitude | 14,000 ft |
